10HL Berkeley Cast Iron Convertible Jet Pumps (1 HP, 1-1/4" Suction, 1" Discharge, 1" Drive, 115/230 Voltage)
| Applications |
| The ProJet HL convertible jet pumps offer a proven cast iron self-priming design available in 1/2 1 HP models. The ProJet HL convertible jets utilize built-in regulators offering easier priming and better range of performance from a complete line of shallow well, 4" double pipe, 2" and 3" single pipe jet packages. APPLICATIONS Water systems and sprinkling for homes, farms and cottages. |
| |
| Features |
| Quality Construction: Close-grained cast iron pump body is a rugged one-piece unit, specially treated to resist corrosion. Drain port provided for easy winterizing. |
|
| Noryl Impeller: Precision-molded for perfect balanceultra-smooth for highest performance and efficiency. |
|
| Precision-Molded Diffuser: Pump primes faster, handles more air, with multi-port, precision-molded, reinforced polypropylene diffuser. |
|
| Pressure Switch: High quality, cut-in and differential pressure setting are adjustable. |
|
| Mechanical Shaft Seal: Precision lapped and highly polished carbon-ceramic, stainless steel construction. Internal design guarantees continuous water lubrication for maximum protection. |
|
| Motor Windings: Superior insulation materials protect against excessive moisture and contaminantsassures prolonged motor life. |
|
| Balanced Rotor: Diecast under high pressures for uniform performance and greater efficiencydynamically balanced. |
|
| Heavy-Duty Ball Bearings: Shielded, permanently lubricated bearings, extensively tested to ensure extended life and smooth, quiet operation. |
|
| Pump and Motor Shaft: 416 stainless steel for maximum corrosion resistance; one-piece threaded shaft for positive impeller drive and alignment. |
|
|
Specifications
|
|
Brand
|
Berkeley
|
|
Catalog Number
|
10HL
|
|
Type
|
Cast iron, self-priming convertible jet pumps
|
|
Series
|
HL
|
|
HP
|
1
|
|
Suction
|
1-1/4"
|
|
Discharge
|
1"
|
|
Drive
|
1"
|
|
Voltage
|
115/230
|
|
Body and Seal Plate
|
Close-grained cast iron
|
|
Impeller
|
High-strength Noryl
|
|
Diffuser
|
Reinforced polypropylene with brass wear ring
|
|
Base
|
Steel, 12 gauge
|
|
Max. Inlet Pressure
|
50 PSI
|
|
Pressure Switch Pre-Set
|
30-50 PSI
|
|
Pressure Gauge
|
0-100 PSI
|
|
Suction Ports
|
Suction-over-Drive
|
Item Number:
10HL
Manufacturer:
Berkeley Pumps
Manufacturer Part No:
10HL
|
|
|
