113893.00 Leeson Motors (C6T34DC66 , 3 HP, 56 Frame, 3450RPM, 208-230/460V, DP)
|
Images may be generic. Please inquire
|
Your Price:
Call For Availability
|
|
Applications |
|
Designed for various applications that you may find in the pumping industry where direct coupled motor to pump is required.
|
|
|
|
Features |
|
NEMA 56 C-Face mounting face |
|
|
Mechanically locked ball bearing on shaft-end, limits axial shaft movement |
|
|
Quiet operation through Super Hush flow-through ventilation system |
|
|
416 stainless steel shafts |
|
|
Quick Connect terminals to reduce installation time |
|
|
Auto re-set protectors |
|
|
Stator windings impregnated with extra heavy varnish system |
|
|
High overload capacities provided by high service factor ratings |
|
|
Double-sealed ball bearings |
|
|
UL and C.S.A recognized |
|
| Specifications | | Brand | Leeson Motors | | Catalog Number | 113893 | | Type | Leeson Electric Motor | | Series | Jet Pump | | Model Number | C6T34DC66 | | HP | 3 | | Frame | 56 | | RPM | 3450RPM | | Voltage | 208-230/460V | | Enclosure | DP | | Warranty | 1 Year | | Notes | See Support Documents |
Item Number:
113893
Manufacturer:
Leeson
Manufacturer Part No:
113893
|
|
|
