30012ET3GKD449T-W22 WEG NEMA Premium Efficiency Motor (300 HP, 447/9T Frame, 3 PH, 460V, 60Hz, TEFC, Foot Mounted)
30012ET3GKD449T-W22 WEG NEMA Premium Efficiency Motor (300 HP, 447/9T Frame, 3 PH, 460V, 60Hz, TEFC, Foot Mounted)
| Frame |
447/9T |
|---|
| Output |
300 HP (220 kW) |
|---|
| Number of Poles |
6 |
|---|
| Frequency |
60 Hz |
|---|
| Rated speed |
1189 rpm |
|---|
| Slip |
0.92 % |
|---|
| Rated voltage |
460 V |
|---|
| Rated current |
356 A |
|---|
| L. R. Amperes |
2741 A |
|---|
| LRC |
7.7x(Code J) |
|---|
| No load current |
170 A |
|---|
| Rated torque |
1310 ft.lb |
|---|
| Locked rotor torque |
270 % |
|---|
| Breakdown torque |
300 % |
|---|
| Locked rotor time |
18s (cold) 10s (hot) |
|---|
| Design |
A |
|---|
| Insulation Class |
F |
|---|
| Service factor |
1.00 |
|---|
| Temperature rise |
80 K |
|---|
| Duty Cycle |
Cont.(S1) |
|---|
| Starting Method |
Direct On Line |
|---|
| Ambient temperature |
-20°C to +40°C |
|---|
| Altitude |
1000 m.a.s.l. |
|---|
| Degree of Protection |
IP55 |
|---|
| Enclosure |
IC411 - TEFC |
|---|
| Mounting |
F-1 |
|---|
| Rotation¹ |
Both (CW and CCW) |
|---|
| Noise level² |
70.0 dB(A) |
|---|
| Approx. weight³ |
3139 lb |
|---|
Item Number:
30012ET3GKD449T-W22
Manufacturer:
WEG
Manufacturer Part No:
30012ET3GKD449T-W22
|
|
|
