388F-98 AMT 1-1/2" Stainless Steel Inline Centrifugal Pump (1/2 HP, 56J Frame, 115/208-230 VAC/60 Hz, 1 Phase, Stainless Casing)
| Applications |
| AMT SS Centrifugal pumps are designed for use with most gravity fed service applications requiring chemical processing and dirty water transfer. All models are fitted with a self-cleaning stainless steel impeller for maximum 1/8" diameter solids handling. Pumps are designed to handle liquids with solids content or dissolved solids and debris. Units feature pull from-rear design for easy servicing without removing piping. Pumps are not self-priming and require flooded suction. |
| |
| Features |
| Stainless Steel Construction |
|
| Max Temp 180 Degrees F. |
|
| Self-Cleaning |
|
| 1/8? Diameter Solids Handling Stainless Steel Impeller |
|
| Buna-N Mechanical Seal and O-Ring |
|
| 1-1/2" x 1-1/2" NPT Thread |
|
| Pull-from-Rear Design for Easy Servicing Without Removing Piping |
|
|
Specifications
|
|
Brand
|
AMT
|
|
Catalog Number
|
388F-98
|
|
Type
|
1-1/2" SS INLINE CENTRIFUGAL PUMP
|
|
Series
|
STRAIGHT INLINE CENTRIFUGAL Pump
|
|
HP
|
1/2
|
|
Frame
|
56J
|
|
VAC/60 Hz
|
115/208-230
|
|
Phase
|
1
|
|
Casing
|
Stainless
|
|
QSP
|
Yes
|
|
Max Suction Lift
|
6"
|
|
Discharge
|
1-1/2"
|
|
Suction
|
1-1/2"
|
|
Notes
|
See Support Documents
|
Item Number:
388F-98
Manufacturer:
AMT
Manufacturer Part No:
388F-98
|
|
|
