AMT Pumps 3S5XLR, 3" Trash Pump (5 HP, LCT 208 CC Driver, Viton Seal, 3" NPT Port, 2.2 Hr Run Time, .71 Gal Tank Size, 290 GPM, 110 Ft Head, 48 PSI)
| Applications |
| IPT Portable High Volume, Self-priming Centrifugal Trash pumps come standard with a cast iron impeller to resist abrasion and one tool serviceability for easy cleanout. All pumps feature aluminum housing, cast iron wearparts, built-in check valve, suction strainer and heavy duty steel roll frame. Heavy duty cast iron flanges with male NPT threads that rotates in 90 increments. Easy access fill plug on discharge port. |
| |
| Features |
| • Cast Iron Impeller |
| • Cast Aluminum with Cast Iron Wearparts |
| • One Tool Serviceability Tool Included with Engine Driven Models |
| • Silicon Carbide Mechanical Seal with Graphite Impregnated Seat and Viton Elastomers |
| • Built-in EPDM/EPR Check Valve |
| • Heavy Duty Steel Roll Frame and Strainer Included |
| • Removable/Replaceable Cast Iron Suction/Discharge Ports |
| • Discharge Port Rotates in 90 Increments |
| • Vibration Dampening Feet |
| • Maximum Temperature 180 F |
| • Max Solids Handling Capacity: 1-1/4" Diameter |
| • Heavy Duty Steel Roll Frame and Strainer Included |
| • Optional Wheel Kit Available |
| • Self-Priming to 26 Ft. |
|
Specifications
|
|
Brand
|
AMT
|
|
Catalog Number
|
3S5XLR
|
|
Type
|
Engine Driven Self-Priming Trash Pumps
|
|
Series
|
3" Trash Pumps
|
|
HP
|
5 HP
|
|
Curve
|
B
|
|
Port
|
3" NPT
|
|
Driver
|
LCT 208CC
|
|
Seal
|
Viton / SIC-SIC
|
|
Run Time (Hours)
|
2.2
|
|
Tank Size (Gal/Ltr.)
|
0.71 / 2.7
|
|
Ship Wt. (Lbs.)
|
100
|
|
Discharge
|
3" NPT
|
|
Suction
|
3" NPT
|
|
Max PSI (Approx.)
|
48 PSI
|
|
Max Total Head
|
110 FT
|
|
Max GPM
|
290 GPM
|
|
Oil Alert
|
Included
|
|
L
|
24.0"
|
|
W
|
19.5"
|
|
H
|
19.9"
|
|
Warranty
|
1 Year
|
|
Notes
|
See Support Documents
|
Item Number:
3S5XLR
Manufacturer:
AMT
Manufacturer Part No:
3S5XLR
MSRP: $324.00
Your Price: $210.39
You Save: $113.61 (35 %)
