AMT Pumps 4851-97, 3/4" Self-Priming Utility Pump (1/8 HP, 12.8V DC, TENV Enclosure, 3/4" NPT Suction and Discharge, Bronze Casing)
| Applications |
| The AMT Self-priming Centrifugal pump is compact and designed for a wide range of dewatering/recirculating applications. |
| The AMT Model 4851-97 Self-priming Bronze Centrifugal pump is compact and designed for a wide range of dewatering/recirculating applications including: marine, salt water aquaculture and live well tanks. Meets U.S. Coast Guard (USCG) Electrical Standards (Title 33, Chapter 1, Part 183, Subpart 1) for Ignition Protection on Gasoline Powered Vessels. |
| Features |
| Cast Bronze Construction |
|
| Buna-N Mechanical Seal and O-Ring |
|
| 3/4 NPT Suction and Discharge Ports |
|
| 1/8 HP, 12 Volt DC, 3700 RPM Motor |
|
| Maximum Suction Lift 4 Ft. |
|
|
Specifications
|
|
Brand
|
AMT Pumps
|
|
Catalog Number
|
4851-97 (Replaced 4850-97)
|
|
Type
|
Utility Pumps
|
|
Series
|
3/4" Self-Priming Utility Pumps
|
|
Curve
|
A
|
|
HP
|
1/8
|
|
PH
|
-
|
|
ENC
|
TENV
|
|
Voltage @ 60 Hz
|
12.8 V-DC
|
|
Full Load Amps
|
11
|
|
Suction
|
3/4" NPT
|
|
Discharge
|
3/4" NPT
|
|
Casing
|
Bronze
|
|
Shaft Seal
|
Buna-N/SS
|
|
Impeller
|
Bronze
|
|
L
|
8.7"
|
|
W
|
4.0"
|
|
H
|
5.1"
|
|
Ship Wt. (Lbs.)
|
9
|
|
Warranty
|
1 Year
|
|
Notes
|
See Support Documents
|
|
Pump Curves
|
See Support Documents Below
|
Item Number:
4851-97
Manufacturer:
AMT
Manufacturer Part No:
4851-999-97
|
|
|
