4SE7524L Barnes Submersible Trash Sewage Pump (7.5HP / 230V / 1PH)
|
Images may be generic. Please inquire
|
Your Price:
Call For Availability
|
| Model Number |
4SE7524L 084627 |
|---|
| Series |
4SE Submersible Trash Sewage Sump Pumps |
|---|
| Warranty (YRS.) |
1 |
|---|
| Max Flow (GPM.) |
725 |
|---|
| TDH Maximum (Ft) |
51 |
|---|
| TDH Maximum (PSI) |
22.08 |
|---|
| Horsepower |
7.5 |
|---|
| Outlet Connection Type |
Flange |
|---|
| Outlet (In.) |
4 |
|---|
| Wetted Materials |
CI |
|---|
| Elastomers / O-ring |
Buna-Nitrile |
|---|
| Voltage (V) |
230 |
|---|
| Phase (Ø) |
1 |
|---|
| Motor Frequency |
60 |
|---|
| Motor |
Hermetically Sealed |
|---|
| Motor Amps (A) |
39 |
|---|
| Speed (RPM.) |
1725 |
|---|
| Self Priming |
Yes |
|---|
| Max Operating Temperature (F) |
105 |
|---|
| Max Particle Size (In) |
3 |
|---|
| Viscosity |
Milk 3.20 cp 40.00 ssu |
|---|
| Length (In.) |
34 |
|---|
| Mechanical Seal |
OIL FILLED |
|---|
| Mechanical Seal Face |
Carbon-ceramic |
|---|
| Mechanical Seal Type |
Double |
|---|
| Motor Bearings |
Double row ball pump end, single row upper end. |
|---|
| Impeller Size (IN.) |
7 |
|---|
| Applications |
Dewatering, Irrigation, Sewage, Submersible, Sump |
|---|
| Other |
Capacitor Start / Capacitor Run via pump control panel.
Discharge centerline is 5.5" high, overall diameter of pump 19.93", Center of pump to face of outlet flange 11.75".
|
|---|
| Approvals |
CSA |
|---|
| Impeller Material |
Cast iron, 2 vane open |
|---|
| Motor Locked Rotor Amps (A.) |
96 |
|---|
| Cord Size |
4-Aug |
|---|
| Cord Length (Ft.) |
25 |
|---|
| Duty |
Continuous |
|---|
| Drain |
Yes |
|---|
| Port Rotation |
Yes |
|---|
|
|
|---|
| Weight (Lbs) |
370 |
|---|
|
|
|---|
Item Number:
4SE7524L
Manufacturer:
Barnes Pumps
Manufacturer Part No:
4SE7524L
|
|
|
