CFW080100B2024EON4A1Z WEG Drive (200-240V, Single/Three Phase, NEMA4X/IP56 Enclosure)

Main Characteristics

• Output current from 1.0 to 33 A (0.25 to 20 cv)
• Single or three-phase power supply
• Supply voltage from 200 to 480 V1)
• Vector (VVC) or scalar (V/F) control
• Accessories to expand functionalities
• Standard, Plus or Wash Versions (IP66/NEMA 4x)
• Multipump control
• Built-in operating and programming interface (HMI)
• Brake IGBT
• Internal (optional) or external (accessory) RFI filter
• Fault or alarm diagnosis
• Optional items for CANopen, DeviceNet, RS485 and RS232 industrial communication networks
• Remote operating interface - HMI (optional)
• Free SuperDrive programming software

Applications

• Multimotors and multipumps
• Centrifugal pumps
• Process dosing pumps
• Fans / exhausters
• Stirrers / mixers
• Extruders
• Conveyor belts
• Roller tables
• Granulators / pelletizers
• Dryers / rotary ovens
• Rotary filters
• Winding machines / uncoiling machines
• Cutting and welding machines

Special Functions and Resources

• Password to enable programming
• Fault self-diagnosis and auto-reset
• Indication of specific quantity (programmable) - (e.g.: m/min, rpm, among others)
• Slip compensation (V/F control)
• Adjustable quadratic and linear V/F curve
• Self-tuning routine (sensorless vector control)
• Dynamic braking
• Momentary speed impulse function (Jog)
• Copy of the setting via serial operating interface - HMI (copy function)
• Linear and “S” type ramps
• Independent acceleration and deceleration ramps
• DC braking (direct current)
• Multispeed function with up to 8 preset speeds
• Selection of the direction of rotation
• Overlapped PID control (automatic control of level, pressure, etc.)
• Start with the motor spinning (flying start)
• Rejection of critical or resonant frequencies (skip frequency)
• Operation during momentary network faults (ride-through)
• Communication protocols: Modbus-RTU, CANopen and DeviceNet
