MSPG Mody Pumps Submersible Grinder Pump (7.5-20 HP, 2" Discharge Connection, 150 Max GPM)
|
Images may be generic. Please inquire
|
Your Price:
Call for Pricing
|
| Applications |
| Submersible Grinder Pump for Dry Pit, Wet Pit, Portable applications. |
| |
| Features |
| EASY RETROFIT TO ABS AND MOST OTHER BRAND INSTALLATIONS |
|
| HIGH EFFICIENCY MOTORS WITH CLASS H (180C) INSULATION SYSTEM |
|
| INTEGRAL ECO-FRIENDLY COOLING SYSTEM |
|
| FAST - CHANGE CARTRIDGE MECHANICAL SEALS WITH SILICON CARBIDE SEAL FACES |
|
| REDUCER SYSTEM - GRINDER MECHANISM CLEARANCE REDUCTION SYSTEM |
|
| SEMI-OPEN, MULTI-VANE, IMPELLER |
|
| FAST - LOCK, QUICK-RELEASE, LATCH-BOLTS |
|
| OIL TAP DRAIN |
|
| POWER CABLE: 25 in length,sized according to IEC, NEC or CSA standards, water/oil resistant EPR insulated, cop per conductor flexible cable and additional control cable for moisture sensor and thermals, capable of continuous submerged operation underwater at temperatures to 90C and to a depth of 66 feet. |
|
| SURFACE TREATMENT: Primer with Epoxy and subsequently coated with black air dry enamel. |
|
|
Specifications
|
|
Brand
|
Mody Pumps
|
|
Catalog Number
|
MSPG
|
|
Type
|
Submersible Grinder Pump
|
|
Series
|
MSPG2
|
|
HP
|
7.5-20
|
|
Discharge Connection
|
2"
|
|
Max GPM
|
150
|
|
Max Shut Off Head
|
350'
|
|
Solid Handling
|
0.393"
|
|
Impeller Type
|
Multi Channel
|
|
Power Supply
|
230/380/460/575 volts
|
|
Cooling jacket system -optional
|
Yes
|
|
Max Starts/Stop per hour
|
15
|
|
Motor- VFD rated
|
2/4 Poles
|
|
Max Temp
|
104 Degrees F.
|
|
Max. Submergence
|
66'
|
|
Power Cable
|
25'
|
|
Construction
|
Cast Iron
|
|
Notes
|
See Support Documents
|
Item Number:
MSPG
Manufacturer:
Mody Pumps
Manufacturer Part No:
MSPG
|
|
|
