P250/HP210WDO-T4F Doosan Portable Air Compressor (250 CFM/210 CFM, 80-175 PSIG, 3/4" Discharge, Doosan 24 Engine)
|
Images may be generic. Please inquire
|
Your Price:
Call for Pricing
|
The P250/HP210-T4F portable air compressor from Doosan Portable Power is ideal for a wide variety of applications. Powered by the reliable Doosan D24 engine, the P250/HP210 produces 250 cfm at 100 psi or 210 cfm at 150 psi, making it the perfect portable air compressor for sandblasting, construction, or pneumatic tool operation. The compact design and versatility of the P250/HP210 make it a natural choice for any job or worksite.
P250/HP210WDO-T4F Air Compressor
**LOW PRESSURE / HIGH PRESSURE**
Free-Air Delivery – cfm (m3/min)250 / (7.0)210 (5.9)
Rated operating Pressure – psig (bar)100 (6.9) / 150 (10.3)
Pressure range – psig (bar) 80 - 175 / (5.5 - 12.1) / 80 - 175 (5.5 - 12.1)
Air Discharge outlet size – in (mm) 0.75 (19.0) / 0.75 (19.0)
Air Discharge outlet Quantity - 2
Fuel Tank Capacity – gal (L) 34.5 (130.6) / 34.5 (130.6)
Make/model: Doosan 24 / Doosan 24
Emissions Tier Level: Tier 4 Final (T4F)
Number of Cylinders: 4
Displacement – cu in (L) 147 (2.4) / 147 (2.4)
Rated speed – rpm 2550 / 2200
Idle speed – rpm 1700 / 1700
Bhp @ rated speed (kW)74 (55.1) / 72.6 (54.1)
Electrical: 12
Hours of operation @ Full Load 8.79.1
Length – (in / mm) 142.7 (3625) / 142.7 (3625)
Width – (in / mm) 68.8 (1746) / 68.8 (1746)
Height – (in / mm) 67.3 (1710) / 67.3 (1710)
Track Width –(in / mm) 60.3 (1530) / 60.3 (1530)
Tire size – 15"
Shipping Weight – w/o fuel – lb (kg) 2357 (1069) / 2357 (1069)
Working Weight – w fuel – lb (kg) 2595 (1177) / 2595 (1177)
Length – (in / mm) 94.6 (2403) / 94.6 (2403)
Width – (in / mm) 49.3 (1252) / 49.3 (1252)
Height – (in / mm) 56.3 (1431) / 56.3 (1431)
Shipping Weight – w/o fuel – lb (kg) 2147 (974) / 2147 (974)
Working Weight – w fuel – lb (kg) 2385 (1082) / 2385 (1082)
Item Number:
P250/HP210WDO-T4F
Manufacturer:
Doosan
Manufacturer Part No:
P250/HP210WDO-T4F
|
|
|
